5 Tons Dongfeng DFAC Rear Load Hook on Garbage Truck
Hook loader truck (also called roll-off garbage truck, roll on roll off truck, hook lifter truck, hook lift garbage truck, carriage removable / dismountable garbage truck, hook loader container truck, garbage collection truck , hook lifter truck etc. ) is designed to collect and transport municipal solid waste, widely used in residence community, hospital, municipal environmental section, garbage transportation station etc.
Loading capacity ranges from 1ton, 2tons, 3tons, 5tons, 8tons, 14tons, 18tons, 20 tons etc
Description
Get quotation
5 Tons Dongfeng 4*2 Rear Load/Hook on Garbage Truck
Hook loader truck (also called roll-off garbage truck, roll on roll off truck, hook lifter truck, hook lift garbage truck, carriage removable / dismountable garbage truck, hook loader container truck, garbage collection truck , hook lifter truck etc. ) is designed to collect and transport municipal solid waste, widely used in residence community, hospital, municipal environmental section, garbage transportation station etc.
Loading capacity ranges from 1ton, 2tons, 3tons, 5tons, 8tons, 14tons, 18tons, 20 tons etc.
Technical Date
| General | Overall Dimension | 9830*2500*3150 mm |
| GVW/Kerb Weight | 25000 kgs/11960 kgs | |
| Cab | Cab capacity | 2 persons allowed with 1 sleeper |
| Air Conditioner | Air conditioner is optional | |
| Engine | Fuel Type | Diesel,Gasoline,Natural Gas |
| Power | 340HP (250KW) | |
| Displacement | 8300ml | |
| Emission Standard | Euro 3 | |
| Chassis | Drive type | 6*4 Left hand drive or right hand drive |
| Transmission | 9 speed forward , 1 reverse | |
| Max Speed | 90 km/h | |
| NO.OF Axle | 3 | |
| Paint | Metallic paint | |
| Superstructure | Loading capacity | 10 Ton ( 18 CBM ) |
| Container Dimension | 6200*2500*2650 mm | |
| Container Weight | 5 Tons | |
| Operation voltage | 380 V | |
| Hopper Capacity | 2CBM | |
| Compressor Power | 5500 W | |
| Compression Room | 1.3 CBM | |
| Recycle Time | 35 - 45 S | |
| Max. Working capacity | 100 Tons / Day | |
| The hook loader consists of underframe , linkage frame ,Fixed arm , Telescopic arm , hook Arm , Locking system , Hydraulic system...... | ||
| Optional | All other standard accessories:Tool kit , English manual ...... | |
