Dongfeng RHD 12CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System
  • Dongfeng RHD 12CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System
  • Dongfeng RHD 12CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System
  • Dongfeng RHD 12CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System
  • Dongfeng RHD 12CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System
  • Dongfeng RHD 12CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System
  • Dongfeng RHD 12CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System
Dongfeng RHD 12CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System
Self Compressed with Rear Loading with different mechanism: Barrel, Steel Container, etc
Leakage Proof Container Design to avoid the pollution.
Hydraulic Control Loading & Unloading System
Automatic Key Control & Hydraulic Handle Control
Best Choice for Garbage Transportation Inside City.
Description FEEDBACK

Dongfeng RHD 12CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System


Self Compressed with Rear Loading with different mechanism: Barrel, Steel Container, etc
Leakage Proof Container Design to avoid the pollution.
Hydraulic Control Loading & Unloading System
Automatic Key Control & Hydraulic Handle Control
Best Choice for Garbage Transportation Inside City.

Dongfeng RHD 10CBM to 18CBM City Cleaning Garbage Compactor Compress Truck With Compression System

Vehicle Parameters

General

Vehicle Model

CLW5120ZYSE5

Vehicle Brand

Chengli

Chassis Brand

Dongfeng

Overall Dimension(mm)

7750×2500×3390

GVW/Curb /Rated loading Weight(kg)

12495/8550/3815

Chassis Parameters

Cab

Cab Seat

2,3

Air Conditioner

Optional

Engine

Fuel Type

Diesel

Engin Model

B170 33

Engine Brand

Dongfeng Cummins

Power(hp)

170

Displacement(cc)

4500

Emmission Standard

Euro3

Chassis

Drive Type

4*2

Transmission

6 speed, Manual

Wheelbase(mm)

3950

Tyre Specification

9.00-20

Tyre No.(pcs)

6+1

Max Speed(km/h)

90

Paint

Blue

Garbage Tank Structure Parameters

Tank Volume

10CBM to 18CBM

Tank Material

Carbon Steel

Tank Thickness

4/5mm

Loading Bunker

0.7cbm

Liquid Drain

Drainage channel, sewage tank

Mechanism of Raising

Two hydraulic cylinders

Standard configuration

Chassis, arc-shaped body, sub frame, rear lifting part, loading bunker, pushing-out plate, hydraulic system, pressing system, sewage tank, climbing ladder, pneumatic control.

Modes of the pressing

Manual, semi-automatic, automatic, lifting rear part operation manual, loading, pushing, pressing, pushing out automatic

Remarks

1. Arc-shaped high-strength steel tank

2. Sewage tank

3. Roll-over stand (available for 240L plastic bucket*2 )
4.High quality hydraulic multi-valve (manual and automatic control

5.Siemens PLC control system
6.Precompressor

The above mentioned figures are approximate.
Optional equipments are included in these photographs
Specifications and dimensions are subject to change without notice.
Material : Anti-corrosion Steel
Material : Anti-corrosion Steel or High-tensile Steel
Material : High-tensile Steel
