5 Ton Dongfeng Dump Truck With a Crane
Our company is appointed by the Ministry of Industry and Information of China which is a manufacturer for producing all kinds of special trucks, and the dump truck with chassis, box and hydraulic system is one of our trucks. The dump truck also names dumper or tipper truck which is cooperated with grab, loader and belt conveyor and used for transporting loose material (such as sand, gravel, or demolition waste) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic rams to lift the front, allowing the material in the bed to be deposited ("dumped") on the ground behind the truck at the site of delivery. Our 5 ton truck mounted crane is your best choice.
Description FEEDBACK

5Ton Dongfeng Dump Truck With a Crane

Our company is appointed by the Ministry of Industry and Information of China which is a manufacturer for producing all kinds of special trucks, and the dump truck with chassis, box and hydraulic system is one of our trucks. The dump truck also names dumper or tipper truck which is cooperated with grab, loader and belt conveyor and used for transporting loose material (such as sand, gravel, or demolition waste) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic rams to lift the front, allowing the material in the bed to be deposited ("dumped") on the ground behind the truck at the site of delivery. Our 5 ton truck mounted crane is your best choice.



1. With sealed structure and lifting hydraulic cylinder function, the dump truck can unload the sand, gravel or demolition waste by gravity to avoid leakage.
2. With enough volume, the dump truck can load more sand, gravel or demolition waste.
3. The whole structure is solid and tight, it can be worked constantly.
4. The side board and top board can be turned automatically.
5. With mature, strong and balanced hydraulic lifting function, the dump truck’s capacity can be reached 10-20T.
6. With automatic turning angle, it saves unloading time and labor to a great degree.
7. Narrowing transporting period, improving production efficiency.
8. With saving transporting cost, the dump truck is popular for transporting.

5Ton Dongfeng Dump Truck

Overview

Name

5 Ton Dongfeng Dump Truck

Dimension(LxWxH)

5990x1960x2380(mm)

Total Mass

8050Kg

Rated Payload

5000Kg

Curb Weight

3050Kg

Passenger

3

Approach/Departure Angle

19/15

The Parameters of Chassis

Manufacture/Model

Dongfeng/EQ1060TJ20D3

Driving Type

4*2 left/right hand drive

Wheel Base

3800 mm

Gearbox

Six speed lever with five speed forward and one reverse, manual

Front/Rear Track

1506/1466(mm)

Tyre

7.00-16

The Number of Tyre

6+1(spare tyre)

Front/ Rear Suspension

1032/1658(mm)

Leaf Spring Number

8/9+5, 6/8+4

The Parameters of Engine

Manufacturer/Model

Chaocai/CY4102-C3F

Rated Power

95hp/70kw

Fuel Type

Diesel

Displacement/Capacity

3856ml

Emission Standard

Euro3

Cylinder

Straight/4/intercooling

Max. torque

340N.m

Velocity

3200rpm
