Dongfeng Jetting Sewage Vacuum Suction Truck With 375HP Deputy Diesel Engine 35m3

1. 35m3 Vacuum Sewage Suction Truck for Large Volume Sewage Tranport

2. Separated 420HP Deputy Engine to support the sewage suctin System

3. High quality truck chassis, as well as famous chinese brand Dongfeng Truck with Cummins Engine

4. 12wheels 12R22.5 Tire or 12R22.5, special design for sewage Suction

5. Good for Diameter less than 1800mm sewer pipe

6. 35,000liter tank capacity which can carry about 30Ton to 32ton sewage.

7. Self Tipping system with rear opening door, With rubber pipe for rust resistant.

Description FEEDBACK

Dongfeng Jetting Sewage Vacuum Suction Truck With 375HP Deputy Diesel Engine 35m3

Sewage Vacuum truck  (also called Suction vacuum truck, vacuum vehicle, Japanese sewage tank truck, Sewage disposal tank trucks, vacuum tank trucks) is used for suction, transportation and dumping soil and mud from various sewer man-hole, water wells and sediment.

Vacuum Tank truck made by Power star Trucks is necessary for city sanitation department, waste processing company, big factory..., it can help to clean the sewer pipe underground, clean the sludge in the river around city, it also can help big factory to clean the greasy dirt and waste water.More specification about the vacuum tank please kindly refer to following information.

Product Description

1. 35m3 Vacuum Sewage Suction Truck for Large Volume Sewage Tranport
2. Separated 375HP Deputy Engine to support the sewage suctin System
3. High quality truck chassis, as well as famous chinese brand Dongfeng Truck with Cummins Engine
4. 12wheels 12R22.5 Tire or 12R22.5, special design for sewage Suction
5. Good for Diameter less than 1800mm sewer pipe
6. 35,000liter tank capacity which can carry about 30Ton to 32ton sewage.
7. Self Tipping system with rear opening door, With rubber pipe for rust resistant. Key Features:

Vehicle information list

Truck brand

Dongfeng

Truck model

CLW5250GXW

Total mass

32000

Tanker volume

25

Rated mass

12820

Vehicle size

11900×2500×3600

Curb weight

12050

Cabin seat

2

A/D angle

16/22

F/R hang

1500/1700

Axles

3

Wheel base

1900+3325+1350

Axles loading

7000/18000/18000(8x4)

Max speed

85





Chassis information list

Chassis model

DAFC

Tyre quantity

10

Tyre size

11.00-20

Leaf spring quantity

10/12,4/12,4/-,10/-

Front track

2022,2041

Fuel type

Diesel

Rear track

1830/1830

Standard

Euro III

Engine model

IISLe375 30

375HP

Water cooled,4-stroke

6-cylinder

Displacement/power

8900ml/275kw

The sucking tanker volume

35m3

Tanker material

Wuhan steel

More tanker equipment

Oily water separator, air water separator, special vacuum excrement suction pump, pressure volume gauge, pipeline system, the sucking tube, flow valve, vacuum tank, a communicating device (as the dung window), automatic anti-overflow valve these parts

Electric system

24v

Equipment

1.Equipped with hermetic dustbin,hydraulic systerm and operatiing system

2.Automatic compress and uninstall,sewage can be collected by the dump tank.

3.Pressure is large,leakproofness is good,operation is convenient and security is demendable

Warranty

12months

Delivery time

20days
