Sinotruck howo 16000Liter Capacity Road Food Grade Milk Tanker Transport Truck

Sinotruck howo 16000Liter Capacity Road Food Grade Milk Tanker Transport Truck

Milk transport trucks (also called fresh milk transport trucks, milk tanker trucks and liquid food transport trucks) are divided by volume (3000L to 45000L)

The tank body of the milk tanker truck is made of food-grade stainless steel plates, and an insulation layer is added on the outside of the tank body to prevent the fresh milk from deteriorating.

Description FEEDBACK

Sinotruck howo 16000Liter Capacity Road Food Grade Milk Tanker Transport Truck

Milk transport trucks (also called fresh milk transport trucks, milk tanker trucks and liquid food transport trucks) are divided by volume (3000L to 45000L)

The tank body of the milk tanker truck is made of food-grade stainless steel plates, and an insulation layer is added on the outside of the tank body to prevent the fresh milk from deteriorating.



Specifications for the milk tank

Tanker volume

16CBM

Material

4MM 304-2B food level stainless steel

Others

With PIC clean system;
With insulating layer, 80mm polyurethane foam, 2mm thickness stainless steel plate outside;
Thermal insulation function: 24 hour medium temperature rise and fall≤1ºC


Main Specifications for 6X4 15,000liters Milk tank truck
(For other tank volume, please contact me directly)

Cabin

Driving type 6x4      LHD/RHD
HW76 cab, with one bed and air condition

Vehicle Main Dimensions

Overall dimensions (L x W x H)mm

9500×2500×3210

Wheel base  (mm)

4300+1350

Wheel track  (front/rear) (mm)

2020/1800

Weight in KGS

Tare Weight

13500

payload

25000

Front axles loading capacity

1x7000

Rear axles loading capacity

2x16000

Max. driving speed(km/h)

90

Engine

Brand

SINOTRUK

Model

WD615.47

Type

4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charged and inter-cooled

Horse Power(HP)

371 HP

Emission standard

Euro 2

Gearbox

HW15710, 10-speed forward and 2 reverse gear

Clutch

Reinforced diaphragm clutch, diameter 430mm

Steering

ZF8098,power steering, hydraulic steering with power assistance

Oil tank

400 liters

Tire

12R22.5 tubeless tyre 11 pcs including one spare tire
