10CBM ISUZU Foam Water Fire Fighting Trucks
Foam fire trucks are equipped with a variety of fire fighting equipment. Foam fire trucks are currently the primary tool for the most basic mobile fire fighting equipment.
Description FEEDBACK

10CBM ISUZU Foam Water Fire Fighting Trucks



Foam fire trucks are equipped with a variety of fire fighting equipment. Foam fire trucks are currently the primary tool for the most basic mobile fire fighting equipment.

Fire engines are usually stationed in the fire department. In the event of an emergency, the fire trucks will arrive at the scene. Most of the fire engines sold are painted in bright red (in some areas they may also be painted with yellow fire engines) and warning lights are installed at the top of the cabin.

At present, the fire engine is the main tool of the fire department, and it is also the most basic mobile fire-fighting equipment. According to the function, fire engines can be divided into tank fire engines, foam fire engines, water tanks and foam box fire engines.

CLW Group specializes in producing all kinds of fire trucks, ranging in weight from 0.5 to 25 tons. As one of the foam water fire fighting truck manufacturers and suppliers in China, we will provide you with the best truck quality, technical support and after-sales service. Quality fire fighting trucks for sale!



1. Capacity: 10CBM Water Tank, 3CBM Foam Tank

2. Passenger In Cab: Double Row Cab, About 5 People.

3. Advanced Technology In Special Automobile.

4. High Quality And Safety.



Description

10CBM ISUZU Foam Water Fire Fighting Trucks

Drive Model

6X4

Chassis

EQ1208

Vehicle Main Dimensions

Dimensions(L x W x H)mm

9550×2500×3400



Wheel base (mm)

4325+1350



Overhang (front/rear) (mm)

1245/2565



Wheel track (front/rear) (mm)

1940/1860



Approach/Departure angle(°)

27/12

Weight in KGS

Curb Weight

11650



GVW.

21700

Max. driving speed(km/h)

90

passenger

2+3

Engine

Model

B210 33



Type

4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling



Horse Power(HP)

210HP



Emission standard

Euro III

Gearbox

8 forwards & 1 reverse

Clutch

Reinforced diaphragm clutch

Steering Gear

Power steering, hydraulic steering with power assistance

Fuel tank (L)

200

Tire

10.00R20tire ,6+1 spare

Brakes

dual circuit compressed air brake

Cab

four doors, double row

Water volumeL

10000

Foam volumeL

3000

Equipment

Fire pump:model:CB10/60 flow:60L/s Pressure: 1.0MPa

Suction Time:≤35s Mounted type:rear position

Fire gun:model:PS50 flow:50L/s Pressure: 1.0MPa

Shooting range(water,foam:)≥65m ,≥60m

Rotation Angle(°):360/-30~80

Operating model:manual
