FOTON Auman 15000 Liter Diesel Oil Transporter Capacity Fuel Tanker Truck

The fuel tank truck is equipped with oiling machine, fueling gun, sea valve,European standard tank mouth, shell cover, self-priming pump,gear pump,double pump,oil absorbing,transmission shaft,special gear pump,pipe system,out and in oil hole,attendant‘s cabinet,safeguard system and so on.

Description FEEDBACK

FOTON Auman 15000 Liter Diesel Oil Transporter Capacity Fuel Tanker Truck

According to your requires, we can do 3 compartments.,4 compartments,even 8 compartments.

The fuel tank truck is equipped with oiling machine, fueling gun, sea valve,European standard tank mouth, shell cover, self-priming pump,gear pump,double pump,oil absorbing,transmission shaft,special gear pump,pipe system,out and in oil hole,attendant‘s cabinet,safeguard system and so on.

Truck Specification

Chassis model

CL5150GYYB3G

Cab

Auman  ETX-2200, with power steering.

Driving Type

4*2 Left hand driving

Max Speed (km/h)

99

Overall dimensionmm

8500*2480*3200

GVWkg

16000

Mass in working orderkg

6705

Tank Capacity (L)

15000

Wheelbasemm

4700

F/R track basemm

1900/1847

F/R overhangmm

1365/2435

Approach/Departure Angel

16/11

Tire

10.00-20 (6+1)

Clutch

Single-plate dry diaphragm spring clutch

Steering

Hydraulic steering with power assistance

Gear box

6-speed

Bridge

Front axle

5T

Rear axle

10T

Enging

Model

Phaser180Ti-30

Fuel Type

Diesel fuel

Type

Water-cooled four-stroke,, direct injection, turbocharged

Exhaustml

5900

Max output power/rotate speed (hp /rpm )

180/2500

Max torque/rotate speed(N.m/rpm)

633/1400-1600

Braking  system

Service Brake

Compressed air brake

Park Brake

Spring energy

Auxiliary brake

engine exhaust brake

Eletric system

24v

Upper-Body  specification

Volume of tank

15m3

Tank shape

Quadrate

Material of tanker

5mm carbon steel

Color of the tanker

According your demands

Equipment

Oil pump

Transport medium

Diesel oil, gasoil or others

Fittings

PTO oil pump

An aluminum alloy European standard manhole

Fuel hose box fitted on both side of tank

An aluminum alloy sea valves

Two Fire extinguisher

One spare tyre

Ladder: For access to top of tank complete with cat walk on top of tank

Heavy-duty rear bumper

FOTON Auman 15000 Liter Diesel Oil Transporter Capacity Fuel Tanker Truck
