HOWO Sinotruck 6cbm Water Tanker 10cbm Sewage Tanker High Pressure Vacuum Suction Truck  For Sale
  • HOWO Sinotruck 6cbm Water Tanker 10cbm Sewage Tanker High Pressure Vacuum Suction Truck  For Sale
  • HOWO Sinotruck 6cbm Water Tanker 10cbm Sewage Tanker High Pressure Vacuum Suction Truck  For Sale
  • HOWO Sinotruck 6cbm Water Tanker 10cbm Sewage Tanker High Pressure Vacuum Suction Truck  For Sale
  • HOWO Sinotruck 6cbm Water Tanker 10cbm Sewage Tanker High Pressure Vacuum Suction Truck  For Sale
  • HOWO Sinotruck 6cbm Water Tanker 10cbm Sewage Tanker High Pressure Vacuum Suction Truck  For Sale
HOWO Sinotruck 6cbm Water Tanker 10cbm Sewage Tanker High Pressure Vacuum Suction Truck For Sale

Tank Material:

Carbon Steel, Stainless Steel, Aluminium Alloy

Sewage Tank Capacity:

16CBM

Loading Capacity:

10tons/12tons

Oading Medium:

Sewage Fecal Waste Water

Sewage Pump:

China Famous Brand/Italy Brand

Drive Model:

4x2/6x4; As Per Sewage Tank Size

Wheelbase:

3800+1400;4300+1350;4600+1350mm

Color:

White; Blue; Green; Yellow; Customized

Description Get quotation

HOWO Sinotruck 6cbm Water Tanker 10cbm Sewage Tanker High Pressure Vacuum Suction Truck

1. Purpose: It used for city and factory sewer cleaning and sewage transportation, it‘s one of our sanitation truck series. Our mission is assist urban sanitation project and make world cleaning!
2. Main parts: Water-gas separator, Oil-gas separator, Sewage pump, Water pump Four way valve etc.
3. Features: It can adopts high pressure water for flushing sewer first and it will be more easier to suction sewage then. And this truck easy for operating and controlled by control panel and control handle.



Tank Material:

Carbon Steel, Stainless Steel, Aluminium Alloy

Sewage Tank Capacity:

16CBM

Loading Capacity:

10tons/12tons

Oading Medium:

Sewage Fecal Waste Water

Sewage Pump:

China Famous Brand/Italy Brand

Drive Model:

4x2/6x4; As Per Sewage Tank Size

Wheelbase:

3800+1400;4300+1350;4600+1350mm

Color:

White; Blue; Green; Yellow; Customized

Condition

New condition/Left hand drive/6x4

Chassis

Brand

SINOTRUK

Curb weight(kg)

11000 kg

Wheelbase(mm)

4350+1300 mm

Dimensions(mm)

9630×2495×3690 mm

Front/Rear Axle loading(kg)

7000/18000 kg

Wheel track (front/rear) (mm)

2040/1860/1860 mm

Front/Rear overhang(mm)

1480/2450 mm

Approach/Departure angle(°)

18/12

Max. driving speed(km/h)

90 km/h

Clutch

Reinforced diaphragm clutch



Brakes

Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake

Steering Gear

Power steering, hydraulic steering with power assistance

Tire

Quantity

10pcs with one spare tire

Specifications

11R22.5

Transmission

Manual type, 8 Forwards and 2 reverses

Cabin

It can accommodate three people. With Air Conditioner



Engine

Brand

SINOTRUK

Fuel type

Diesel

Displacement(ml)

9726 ml

Horsepower(HP)

266/290/336/371HP

Cylinder number

6

Emission standard

Euro 2

Sewage Suction & Cleaning System

Sewage tank

Capacity(cbm)

12.0 cbm

Tank material

Q235 carbon steel

Thickness(mm)

5.0 mm

Water tank

Capacity(cbm)

4.0 cbm

Tank material

Q235 carbon steel

Thickness(mm)

4.0 mm

Sewage pump

Brand

Jourp(Italy brand)

Model

PN106-D

Max. Vacuum()

92

Max. Absolute pressure(Bar/MPa)

1.5 Bar/0.15 Mpa

Power at 1.5 bar absolute pressure(kw)

13.6 kw

Max. Speed(R.P.M)

1300 rpm

High pressure water pump

Model

HPP(Italy brand)

Rate flow(L/min)

210.0

Remarks

1, 60m high pressure water hose

2, 10 pcs high pressure cleaning nozzle(Italy brand)

3, Hydraulic Control Suction Hose

4, The color is optional
