ISUZU 6x4 20CBM Commercial Container Water Truck For Water Delivery
  • ISUZU 6x4 20CBM Commercial Container Water Truck For Water Delivery
  • ISUZU 6x4 20CBM Commercial Container Water Truck For Water Delivery
  • ISUZU 6x4 20CBM Commercial Container Water Truck For Water Delivery
  • ISUZU 6x4 20CBM Commercial Container Water Truck For Water Delivery
  • ISUZU 6x4 20CBM Commercial Container Water Truck For Water Delivery
ISUZU 6x4 20CBM Commercial Container Water Truck For Water Delivery

1. Optional chassis brand of 20CBM water truck : Dongfeng, Sinotruk, FOTON/Forland, Faw, Shacaman and ISUZU.

2. Material of 20CBM water truck :High Tension Steel Q235/Q345,stainless steel 304 for option.Tank Material in 5mm body
Description FEEDBACK

ISUZU 6x4 20CBM Commercial Container Water Truck For Water Delivery


1. Optional chassis brand of 20CBM water truck : Dongfeng, Sinotruk, FOTON/Forland, Faw, Shacaman and ISUZU.

2. Material of 20CBM water truck :High Tension Steel Q235/Q345,stainless steel 304 for option.Tank Material in 5mm body

3. Sprinking Width of 20CBM water truck :>14M

4. Rear working platform with water cannon range of 20CBM water truck :28M

5. Reliable and high quality water pump

6. CO2 shield automatic welding of whole water tank

7. X-ray testing,gas leakage test and hydraulic test to avoid cold solder joint

8. inner tank anti-corrosion layer of 120micro eposy resin and outer tank with anti-rust painting.

9. Optional for insulation layer and suitable for warm water delivery



Condition

New condition/Left hand drive/6x4

Chassis

Curb weight(kg)

12380 kg

Wheelbase(mm)

4565+1370 mm

Dimensions(mm)

10160*2550*3055 mm

Wheel track (front/rear) (mm)

1960/1860 mm

Front/Rear overhang(mm)

1250/2300 mm

Approach/Departure angle(°)

20/10 °

Max. driving speed(km/h)

100 km/h

Clutch

Reinforced diaphragm clutch

Brakes

Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake

Steering Gear

Power steering, hydraulic steering with power assistance

Tire

Quantity

6pcs with one spare tire

Specifications

12R22.5

Transmission

Manual type, 10 Forwards and 2 reverses

Cabin

Single row seat, Tiltable. It can accommodate three people. With air conditioner.

Engine

Brand

6UZ1-TCG51

Fuel type

Diesel

Displacement(ml)

9839 ml

Power(kw)

257 kw

Horsepower(HP)

349 HP

Cylinder number

6

Emission standard

Euro 5

Upper

Water tank

Capacity(cbm/tons)

20.0

Tank material

Q235 carbon steel

Thickness(mm)

5.0

Water pump

China local brand

Function

1, Front Side Rear Sprinkling width≥14m

2, Water cannon range≥28m

Remarks

1, Air conditioning

2, AM/FM radio

3, 2pcs 3m/5m water hose

4, Color is optional
