Foton 11000 Liters Foam Fire Vehicles With Soncap

FOTON 4*2 fire truck

Drive Model

4*2

Chassis

BJ1253VLPJE

Fact cubage

11.655cbm(water tank:9cbm, foam tank 2.655cbm)

Vehicle Main Dimensions

Dimensions(L x W x H)(mm)

9905x2480x3500

Wheel base (mm)

4300+1350

Overhang (front/rear) (mm)

1555/2600

Wheel track (front/rear) (mm)

2005/1865/1865

Approach/Departure angle(°)

18/16

Weight in KGS

Curb Weight

12040

GVW.

24490

Max. driving speed(km/h)

90

Engine

Model

WP10.270

Type

4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling

Horse Power(HP)

270

engine capacity(ml)

199

Emission standard

Euro III

Gearbox

8 forwards & 1 reverse

Clutch

Reinforced diaphragm clutch

Steering Gear

Power steering, hydraulic steering with power assistance

Fuel tank (L)

200

Tire

12.00R20 , 10pcs + 1 spare

Brakes

dual circuit compressed air brake

UPPER

Water tank Volume

9cbm

Foam tank Volume

2.655cbm

Loading Capacity

11.655

Protective material

Carbon steel

Key Equipment

Fire Pump

Mode

CB30.60

Flow

60L/s

Pressure

1.0Mpa

Fire Monitor

Mode

PL48

Pressure

1.0-1.2MPa

Flow

48L/S

Fire Distance(water/foam)

≥65m/60m

Rotation Angle(°)

360/-30~80
