Danyun 2 Axle 8 Ton Dump Truck for Sales

Model	DYQ3161D5AB
Brand Name	CLW group
Type of vehicle	Dump truck
Country of origin	China
Chassis	DYQ3161D5AA

Description Get quotation

Danyun 4*2 2 Axle 8 Ton Dump Truck For Sale

Model DYQ3161D5AB

Brand Name CLW Group

Type of vehicle Dump truck

Country of origin China

Chassis DYQ3161D5AA

Technical specifications

# Engine model Engine displacement Engine power

1 YC4E160-56 4260 cc 4.3 L 118 kW 161 hp

Performance

Fuel diesel fuel

Environmental standard GB17691-2005 National V / Euro 5, GB3847-2005

Maximum speed 80 km/h 50 mph

ABS have

Capacity

Rated load capacity 7855 kg 7.9 t 17,317 lbs

Load factor (the ratio of the payload of a vehicle to its weight) 1.01

Weights and Ground pressure

Curb weight 7950 kg 8 t 17,527 lbs

Gross vehicle weight rating 16000 kg 16 t 35,000 lbs

Axle load distribution 6000 kg / 10000 kg

6 t / 10 t

13,000 lbs / 22,000 lbs

Dimensions

Overall length 6350 mm / 6650 mm / 6900 mm / 7150 mm 20′10″ / 21′10″ / 22′8″ / 23′6″

Overall width 2400 mm / 2500 mm 7′11″ / 8′3″

Overall height 2850 mm 9′5″

Cargo body

Cargo body length 4000 mm / 4200 mm / 4450 mm / 4700 mm 13′2″ / 13′10″ / 14′8″ / 15′6″

Cargo body width 800 mm 2′8″

Cargo body height 2200 mm / 2300 mm 7′3″ / 7′7″

Undercarriage and Suspension

Number of axles 2

Wheelbase 3400 mm,
3600 mm,
3750 mm,
3900 mm 11′2″,
11′10″,
12′4″,
12′10″

Front track 1875 mm,
1825 mm,
1800 mm 6′2″,
6′0″,
5′11″

Rear track 1860 mm,
1820 mm,
1800 mm 6′2″,
6′0″,
5′11″

Front/rear overhang 1300 mm / 1650 mm,
1300 mm / 1750 mm,
1300 mm / 1850 mm,
1300 mm / 1950 mm 4′4″ / 5′5″,
4′4″ / 5′9″,

Angle of approach 22°

Angle of departure 23°

Leaf springs 8 / 10+8, 8 / 11+8, 9 / 10+8, 9 / 11+8

Tyres and Wheels

Number of tyres 6

Tyres dimension 9.00R20, 10.00-20, 10.00R20

Miscellaneous

Seating capacity 3

#	Engine model	Engine displacement			Engine power
1	YC4E160-56	4260 cc	4.3 L	118 kW	161 hp

Performance
Fuel	diesel fuel
Environmental standard	GB17691-2005 National V / Euro 5, GB3847-2005
Maximum speed	80 km/h	50 mph
ABS	have

Capacity
Rated load capacity	7855 kg	7.9 t	17,317 lbs
Load factor (the ratio of the payload of a vehicle to its weight)	1.01
Weights and Ground pressure
Curb weight	7950 kg	8 t	17,527 lbs
Gross vehicle weight rating	16000 kg	16 t	35,000 lbs
Axle load distribution	6000 kg / 10000 kg 6 t / 10 t 13,000 lbs / 22,000 lbs

Dimensions
Overall length	6350 mm / 6650 mm / 6900 mm / 7150 mm	20′10″ / 21′10″ / 22′8″ / 23′6″
Overall width	2400 mm / 2500 mm	7′11″ / 8′3″
Overall height	2850 mm	9′5″

Cargo body
Cargo body length	4000 mm / 4200 mm / 4450 mm / 4700 mm	13′2″ / 13′10″ / 14′8″ / 15′6″
Cargo body width	800 mm	2′8″
Cargo body height	2200 mm / 2300 mm	7′3″ / 7′7″

Undercarriage and Suspension
Number of axles	2
Wheelbase	3400 mm, 3600 mm, 3750 mm, 3900 mm	11′2″, 11′10″, 12′4″, 12′10″
Front track	1875 mm, 1825 mm, 1800 mm	6′2″, 6′0″, 5′11″
Rear track	1860 mm, 1820 mm, 1800 mm	6′2″, 6′0″, 5′11″
Front/rear overhang	1300 mm / 1650 mm, 1300 mm / 1750 mm, 1300 mm / 1850 mm, 1300 mm / 1950 mm	4′4″ / 5′5″, 4′4″ / 5′9″,

Angle of approach	22°
Angle of departure	23°
Leaf springs	8 / 10+8, 8 / 11+8, 9 / 10+8, 9 / 11+8

Tyres and Wheels
Number of tyres	6
Tyres dimension	9.00R20, 10.00-20, 10.00R20

Danyun 4*2 2 Axle 8 Ton Dump Truck For Sale
