8 Ton and 10 Ton Foton Refrigerated Truck Box Freezer Van with Lifting Plate
refrigerated cold room van truck is also called refrigerated Truck , It is fully enclosed truck which is usually equipped with refrigeration unit and polyurethane insulation layer, is
mainly used in transporting frozen or fresh goods,such as frozen foods,milk products, vegetable,fruit,vaccine, medicines,etc.
Description
Get quotation
Dayun 130HP Electric engine refrigerated truck,16 cubic meters of box refrigerated trucks
Specifications of refrigerated cold room van truck:
refrigerated cold room van truck is also called refrigerated Truck , It is fully enclosed truck which is usually equipped with refrigeration unit and polyurethane insulation layer, is
mainly used in transporting frozen or fresh goods,such as frozen foods,milk products, vegetable,fruit,vaccine, medicines,etc.
Product advantage:
1. Factory export department directly sale
2. Export experience more than 12 years
3. Cheap / competitive price, high quality ,you get more than your paid
4. With CCC, ISO , BV approved
5. The heart of the service, rational design
Product Parameter:
| Type | 4 * 2 refrigerated van truck |
| Brand | FOTON |
| Emission Standard | Euro 4 |
| Cab | One and half row, with A/C |
| Vehicle Description | |
| Overall dimensions(mm) | 9360 * 2490 * 3765 |
| G.V.W (kg) | 16000 |
| Curb weight(vehicle) (kg) | 7260 |
| Loading capacity (kg) | 8000 |
| Whole vehicle main performance | |
| Max speed (Km/h) | 95 |
| Engine | |
| Engine model | ISF3.8S5168 |
| Maximum power (kw) | 125kw / 168hp |
| Displacement (lit) | 3760 |
| Number of cylinders | 4 |
| Type of fuel | Diesel |
| Chassis Description | |
| Chassis model | BJ1166VJPEN-1 |
| Wheel base (mm) | 5250 |
| F / R overhang (mm) | 1350 / 2760 |
| F / R tread (mm) | 1810 / 1907 |
| Gear box | 8 forwards & 1 reverse |
| Spring plate | 8 / 10 + 8 |
| Type of fuel | Diesel |
| Brake system | Air braking |
| Operation control system | Power Steering |
| Electric system | 24V |
| Tires & Quantity | 9.00R20L & 6+1 |
| The Description for Refrigerated | |
| Dimension (mm) | 6720 * 2320 * 2315 |
| Fact volume (M3) | 35 |
| Material | The fiber-glass between the inner-outer color plate |
| Independent refrigeration unit | Equipped with the K693 independent refrigerated unit |
| Temperature range | -10°C |
| Heat preservation layer | 8cm |
| Side door | For your optional |
| The standard parts of van | Stainless lock,stainless cornerite,stainless frame,dome light,bumper block,ventilating slot |
