Jmc 3 Cubic Meter Refrigerated Van Truck for Sales

JMC refrigeration box cold room van freezer refrigerated truck for sale
1 refrigerated units temperature range from -18 degree to 30 degree
2 FRP material insulated box body
3 refrigerated box truck loading weight from 2 ton to 30 ton

Description Get quotation

JMC 3 Cubic Meter Refrigerated Trucks/refrigerated van truck for sales

JMC refrigeration box cold room van freezer refrigerated truck for sale
1 refrigerated units temperature range from -18 degree to 30 degree
2 FRP material insulated box body
3 refrigerated box truck loading weight from 2 ton to 30 ton

refrigerator truck, refrigerated van truck, which is mainly used for transporting the object which need to keep low temperature for fresh. Such as the ice cream, meat,vegetable,also include the medical drug, and so on.
This kind of truck is special designed, the truck cargo box is made with special material to keep temperature, and also install the refrigerator device to refrigerate the inside air,the temperature could reach -18 degree.

Main specification
Product model and name	CLQ5060XLC4 Refrigerator truck
Gross weight(Kg)	5790	Drive type		4x2
Payload(Kg)	2500	Overall dimension(mm)		5990×1950×2880
Curb weight(Kg)	3160	Cab seats		2
Approach/departure angle(°)	27/16	Front/rear hang(mm)		1015/1615
Axle No.	2	Wheelbase(mm)		3360
Axle load(Kg)	2200/3590	Max speed(Km/h)		80
Chassis specification
Chassis model	JX1060TG24	Manufacturer		Hubei Weiyu
Brand name	JMC	Dimension(mm)		5825×1880×2020
Tyre specification	7.00R16LT	Tyre No.		6
Steel spring number	7/5+5	Front track base(mm)		1385
Fuel type	Diesel	Rear track base(mm)		1425
Emission standard	Euro 4	Transmission		5 forward gear,1 reverse gear
Cab	Single row, luxurious interiors and seats with power steering. Air condition is optional.
Engine information	Engine model		JX493ZLQ4
	Engine manufacturer		Jiangling Auto Co.,Ltd
	Displacement(ml)/ Power(Kw)		2771/80(109hp)
	Max Torque		220 N.m
	Speed at Max Torque		3800 rpm
Performance
Van body size(mm)	4200×1750×1750	Load capacity(TON)		3
Lowest refrigeration temperature(ºC)	-18 Centigrade
Feature and Application
The refrigerator truck is the closed van truck that is used to transport the frozen or fresh goods. This truck is made up of vehicle chassis, Polyurethane insulation van, refrigeration unit and temperature recorder. It is commonly used to transport the frozen food, dairy products, vegetable and fruit and vaccine medicine etc. For the special requirements of trucks,such as the meat transportation, the meat hook, aluminum alloy guide rail and ventilation slots etc. parts can be chosen and installed.
