Dongfeng 6 wheels Cummins Engine 8cbm 8000liters Water Tanker Fire Fighting Truck
  • Dongfeng 6 wheels Cummins Engine 8cbm 8000liters Water Tanker Fire Fighting Truck
  • Dongfeng 6 wheels Cummins Engine 8cbm 8000liters Water Tanker Fire Fighting Truck
  • Dongfeng 6 wheels Cummins Engine 8cbm 8000liters Water Tanker Fire Fighting Truck
  • Dongfeng 6 wheels Cummins Engine 8cbm 8000liters Water Tanker Fire Fighting Truck
  • Dongfeng 6 wheels Cummins Engine 8cbm 8000liters Water Tanker Fire Fighting Truck
  • Dongfeng 6 wheels Cummins Engine 8cbm 8000liters Water Tanker Fire Fighting Truck
Dongfeng 6 wheels Cummins Engine 8cbm 8000liters Water Tanker Fire Fighting Truck
Model:CLW5140GXFSG50
Series:Dongfeng 153
The fire trucks is also called fire engine, fire engine truck, fire fighting truck, fire fighting water pump truck, pump fire truck, etc. As a professional fire engine truck manufacturer in China, the fire truck for sale are water tanker fire truck, foam fire truck, emergency rescue fire truck,etc.

Description Get quotation

Dongfeng DFAC 6 Wheels Cummins Engine 8cbm 8000liters Water Tanker Fire Fighting Engine

Model:CLW5140GXFSG50
Series:Dongfeng 153
The fire trucks is also called fire engine, fire engine truck, fire fighting truck, fire fighting water pump truck, pump fire truck, etc. As a professional fire engine truck manufacturer in China, the fire truck for sale are water tanker fire truck, foam fire truck, emergency rescue fire truck,etc.


The chengli fire engine truck are  Dongfeng fire truck, HOWO fire truck, JAC fire truck, etc.  It is max. keeping the original capability of chassis and have the advantage of the advanced

technology,reliable capability, easily operate and so on. The fire truck is the perfect fire fighting

equipment for special fire team.

The fire truck for sale is consisted of truck chassis, water tank, fire pump, fire monitor,

pipeline system, sandwich power take off, storage compartment, electric system,etc.  We have

mini fire engine truck, heavy duty fire engine truck.
CLW DONGFENG 4*2 8 Tons water tank fire fighting truck
Item No. Parameters
Overall Dimension 8150*2500*3450 mm
Drive model 4x2, new condition
GVW 16000 kg
Curb Weight 9750 kg
Loading weight 6150 kg
Wheel Base 4500 mm
Front/rear Overhang 1440/2095 mm
Front/rear Tread 1900/1800mm
Approach/Departure Angle 19/13 degree
Engine Cummins ENGINE B19033
Engine horsepower 190 HP Euro 3
Displacement 5.9 L(Diesel)
Full loading Fuel Consumption Rate 140 G/KW.H
Max Driving Speed 85 km/h
Gear Box 6 Forward Gear, 1 Backward Gear
Tire 10.00R20 ,6 pieces with 1 spare tire.
Tank parameter
Water volume(m³) 8 CBM
Material of the tank Carbon steel
Type of fire pump Centrifugal pump
Fire fighting pump suction depth 7m
Standard equipment Middle and low pressure pump CB10/40
Flow : 40L/S;
Pump Pressure: 1.0 MPa;
Pipes pressure: 1.0 MPa
Fire Distance(water): >=60m
Fire fighting pump suction time:<35s
Delivery outlet(B/S type) :65mm(21/2)
Rotation angle of fire fighting turret nozzle:360degree

Fire Truck Standard Configuration Spare Parts list:
NO. ITEM Q.T.Y UNIT
1 Suction Tube 100-125 2 meters 2100-125 4 Length of
2 Water Filter 100-125    100-125             1 unit
3 Suction Tube wrench 2 unit
4 Ground fire wrench 1 unit
5 Underground Fire wrench 1 unit
6 Water belt 65#     5 roll
7 Water belt 80#   5 roll
8 Outer-affusion water belt 2 roll
9 Different diameter interface 80-65  2 unit
10 DC water gun 1 unit
11 Flowering water gun 1 unit
12 DC switch water gun 1 unit
13 Foam gun 2 unit
14 Same diameter interface 100-125   1 unit
15 Tri-detaching water equipment 80-65       1 unit
16 Water collection 1 unit
17 Water belt guard bridge                    1 Set of
18 Water belt Wrapper                  4 unit
19 Water belt hook               4 unit
20 Fire Hammer 1 unit
21 Fire axe                  1 unit
22 Fire xin               1 unit
23 Fire Ting   1 unit
24 Fire pickaxe 1 unit
25 Fire barrel 1 unit
26 Axe 1 unit
27 soft ladder 1 Set of
