Fire Fighting TruckYou are here：HOME >> Products >> Fire Fighting T...

Sinotruck howo 6 Tyre 2 Axle Right Hand Drive 3000Liters To 4000Liters Water Tanker Fire Truck

The fire engine is also called fire engine, fire truck, fire fighting truck, fire fighting water pump truck, pump fire truck, etc. As a professional fire engine truck manufacturer in China,the fire truck for sale are water tanker fire truck, foam fire truck, emergency rescue fire truck,etc.

Description Get quotation

Sinotruck howo 6 Tyre 2 Axle Right Hand Drive 3000Liters To 4000Liters Water Tanker Fire Truck

The fire engine is also called fire engine, fire truck, fire fighting truck, fire fighting water pump truck, pump fire truck, etc. As a professional fire engine truck manufacturer in China,

The clw fire truck are Dongfeng fire fighting truck, HOWO fire fighting truck, JAC fire fighting truck, etc. It is max. keeping the original capability of chassis and have the advantage of the

advanced technology,reliable capability, easily operate and so on. The fire truck is the perfect fire fighting equipment for special fire team.

The fire fighting tanker truck is consisted of truck chassis, water tank, fire pump, fire monitor,

pipeline system, sandwich power take off, storage compartment, electric system,etc. We have

mini fire engine truck, heavy duty fire engine truck.

Main feature of chengli fire fighting trucks

1.The special part of fire fighting truck include Liquid tanker, pump compartment, equipment compartment, pipe system, electrical system and so on.

2.The fire truck is double integral structure, broad view, 5 to 6 passengers, the fire fighting truck can be put the fire during driving, long range, fire fighting force.

3.The tank inner is with anti-wave plate and tank top is anti-skid checkered plate. Also, the manhole is with fast lock setup and open device.

4.optional: normal fire pressure pump, middle-low pressure fire pump, high-low pressure fire pump.

5.The compartment using high-quality steel, high strength aluminum alloy profiles, inner and outside using corrugated aluminum, multi-channel inside of tanker body.

6.Perfect electrical equipment:cab top alarm lamp, courtesy lamp, both sides flashing light, 100wsiren, vacuum gage, pressure gage, content gage, etc.

Technical Parameters of euro3 diesel right hand drive fire truck for sale

Items	Descriptions	Specifications and Types
General	Truck Name	Fire Truck
	Drive Type	4*2
	Gross Vehicle Weight(kg)	10000
	Curb Weight (kg)	5000
	Overall Dimensions (mm)	6900×2200×2980
Engine	Engine Brand	Yun Nei
	Fuel Type	Diesel
	Power	116HP
	Emission Standard	Euro III
	Displacement(ml)	3760
	Engine Type	4 cylinders in line, water cooling, turbo-charged diesel engine, inter-cooling
Chassis	Chassis Brand	HOWO
	Cab	Double row cab, flat roof
	Tire No.	6+1
	Tire Specification	8.25R16 Steel Tire
	Wheelbase (mm)	3360
	Axle No.	2
	Steering Wheel	Right Hand Drive with power-assisted
	Gear Box	6 speed forward with 1 reverse, manual
	Brake	Air brake
Tank	Water Tank Volume(L)	3000
Tank	Foam Tank Volume(L)	1000
Fire Pump	Pump Model	CB10/30
Fire Pump	Flow	30L/s (Pressure:1.0MPa)
Fire Monitor	Monitor Model	PL24
	Flow	24L/S
	Rotation degree	Horizontal:360°
	Range	Foam: more than 55m, Water: more than 60m
Equipment	Equipped with electric siren, rotation lamp, external ladder, fire fighting hose, suction hose, water filter, fire gun, hydrant wrench, suction wrench, water collection, water belt guard bridge, Water belt wrapper, water belt hook, fire axe, pick hammer, spade.

Sinotruck howo 6 Tyre 2 Axle Right Hand Drive 3000Liters To 4000Liters Water Tanker Fire Truck
