HOWO 10cbm 4*2 Diesel Compactor Garbage Truck Price for Sale
Sinotruk Howo 8 ton Garbage compactor truck Chassis configuration: Sinotruk original chassis, wheelbase 3.8 meters, Sinotruk Howo light truck white cab, 120 horsepower engine in the cloud, 6-speed gearbox, power steering, air brake, 750 tires with spare tires.
Description FEEDBACK

HOWO 10cbm 4*2 Compactor Garbage Truck manufacturers

Sinotruk Howo 8 ton Garbage compactor truck Chassis configuration: Sinotruk original chassis, wheelbase 3.8 meters, Sinotruk Howo light truck white cab, 120 horsepower engine in the cloud, 6-speed gearbox, power steering, air brake, 750 tires with spare tires.

Sinotruk Howo 8 ton Garbage compactor truck Bodywork configuration: Compressed volume of 8 cubic meters, made of T420 special steel plate integrally bent, equipped with Xiamen Yinhua hydraulic cylinder oil leakage replacement, Changyuan 50 hydraulic pump, Zhongmei multi-way valve, Siemens PLC control, electro-optical switch, 2 sewage Collection box, 3 operation control boxes, with night light, equipped with two-way compression function, the two-way hydraulic lock does not leak water.

Sinotruk Howo 8 ton Garbage compactor truck Optional configuration: optional double pump confluence + double valve control, optional hanging bucket rack, triangle bucket, fully sealed bucket, swing arm device, 120-140 barrels of garbage can be installed, and the power is large.


Specification of Howo Truck
General Parameter Drive model 4x2 LHD
Curb Weight 16000KGS
Approach/Departure angle 18/15
Overall Dimensions 9080×2300×3250
Wheel Base 5000 mm
Overhang (front/rear) 1240/2540
Leaf Spring 11/11+7
Tire Quantity 6
Tire Type 8.25R20
Max. Driving Speed 95km/h
Cab Passenger 3 person
Gearbox 5 shifts
Engine Parameter Engine Model WD615.87
Fuel Diesel
Intake Type Vertical, vertical, water cooling, four strokes
MAX Power 290 hp
Emission standard Euro 3
Cylinder Number 4
Cylinder Arrangement In-line
Rated Speed 1800rpm
Displacement 4.257L

Specification of 10cbm garbage compactor box
Upper Parameter Tanker body material Q235A
Shape rectangular box
Thickness Side: 4mm, bottom: 4mm
Payload capacity 10 m³
Equipment Equipped with dustbin, hydraulic system and operating system
Equipped with two advanced double acting hydro cylinders
One vehicle can cooperate with several dustbins to improve the ability of cycle operation. cycling time60s
System of loading Mechanized, rear loading
Loading bunker Volume 1.5 m3
Operation control system Electrically hydraulic control
Lifting capacity ≥800 kg
Liquid drain Drainage channel, sewage tank
Working zone Lighting 2 lamps
Mechanism of raising Two hydraulic cylinders
Ensuring tightness Between the body and lifting back part in the lower part profile acid-proof rubber is used.
Pressing system Pressure 16Mpa
Compaction ratio  1:4
Loading cycle 25-30 second
Unloading cycle 15-20 second
pressing mechanism The giving plate and  hinge related pressing plate moving on two directing bars
Pressing mode Automatic pressing
Control of  pressing Control from the external panel on the bunker
Selective configuration PLC electric automatic control, multifunctional rear lifting part, rear handrail and footplate, other shapes of body, rear swing arm, and etc.
