HOWO 266hp 336hp 6wheeler Skip Loader Garbage Bin Truck
  • HOWO 266hp 336hp 6wheeler Skip Loader Garbage Bin Truck
  • HOWO 266hp 336hp 6wheeler Skip Loader Garbage Bin Truck
  • HOWO 266hp 336hp 6wheeler Skip Loader Garbage Bin Truck
  • HOWO 266hp 336hp 6wheeler Skip Loader Garbage Bin Truck
  • HOWO 266hp 336hp 6wheeler Skip Loader Garbage Bin Truck
  • HOWO 266hp 336hp 6wheeler Skip Loader Garbage Bin Truck
HOWO 266hp 336hp 6wheeler Skip Loader Garbage Bin Truck
Skip loader vehicle (also called skip loader truck, skip loader vehicle, skip loader garbage truck, swing arm garbage truck, telescopic arm skip loader, multi skip loader truck ) is a garbage truck with detachable body container. Which could enable one truck with several garbage containers for recycle use.

It could be equipped with a cover to prevent dropping any rubbish.
Description FEEDBACK

HOWO 266hp 336hp 6wheeler Skip Loader Garbage Bin Truck


Skip loader vehicle (also called skip loader truck, skip loader vehicle, skip loader garbage truck, swing arm garbage truck, telescopic arm skip loader, multi skip loader truck ) is a garbage truck with detachable body container. Which could enable one truck with several garbage containers for recycle use.

It could be equipped with a cover to prevent dropping any rubbish.

Chassis Description

Cab

One and half row non-longhead cab can turn over

Color

Optional

Allowable person in cab

2/3

Wheel base (mm)

4500

Number of axles

2

Front axle

5000

Rear axle

10000

Traction system

4×2

Tire specification

10.00R20

Tire quantity

6+1

Engine Description

Engine manufacture

WEICHAI Engines

Engine model

YWD615 69

Emission standard

Euro 2

Exhaust/output

9726ml/247kw

Horse power

336hp

Up-parts Description

Material of garbage container

Q235 carbon steel

Operation control system

Electrically hydraulic control

Swing arm operating system

Power take-off, balance valve, oil pipe, fuel tank, oil pump, manual mutil-way reversing valve, balance valve, one-way hydraulic lock, etc.

Especially suitable for

Short distance transportation, sanitation department cleaning, transportation, etc.

Swing arm maximum pivot angle

145°

Hoisting time

30s

Unloading time

50s
