ISUZU Outdoor Digital Advertising Billboard Truck With P6 LED Display Screen
  • ISUZU Outdoor Digital Advertising Billboard Truck With P6 LED Display Screen
  • ISUZU Outdoor Digital Advertising Billboard Truck With P6 LED Display Screen
  • ISUZU Outdoor Digital Advertising Billboard Truck With P6 LED Display Screen
  • ISUZU Outdoor Digital Advertising Billboard Truck With P6 LED Display Screen
  • ISUZU Outdoor Digital Advertising Billboard Truck With P6 LED Display Screen
  • ISUZU Outdoor Digital Advertising Billboard Truck With P6 LED Display Screen
ISUZU Outdoor Digital Advertising Billboard Truck With P6 LED Display Screen
LED display, also called led screen, led video wall, or led sign, with its unique advantages, has gradually replaced the traditional billboards, light boxes, etc. LED display advertising has become a new force in the media industry.
Traditional advertising can only show pictures, But LED display/led video wall/led screen can perfect combine text, pictures, video, and sound with high resolution, high brightness and full colour!
Description FEEDBACK

ISUZU Outdoor Digital Advertising Billboard Truck With P6 LED Display Screen




LED display, also called led screen, led video wall, or led sign, with its unique advantages, has gradually replaced the traditional billboards, light boxes, etc. LED display advertising has become a new force in the media industry.
Traditional advertising can only show pictures, But LED display/led video wall/led screen can perfect combine text, pictures, video, and sound with high resolution, high brightness and full colour!

LED display Advertising screen can easily attract the attention of pedestrians, and also are easy to remember, which can generate greater advertising effectiveness.Led display screen now are widely applied in media advertising, transportation, Security,Real estate and Stage show background.

Product Description
1. Purpose: For mobile advertising, products promotion, branding, draft activities, concerts, and sport events, etc.
2. Main parts: LED screen, Generator set, Computer, Control system etc.


Chassis Specification

Item No.

Parameters

Drive model

4x2, 6 Wheels

Overall Dimension

5995×2040×2990(mm)

Chassis Brand

ISUZU 100P

Cabin

Single, Left Hand Driving, with ABS

Engine

Model

4JB1CN, 4 Cylinders

Power

72KW/98HP

Emission standard

EUROIV

Displacement

2771(ml)

Fuel type

Diesel

Gearbox

5 Forward & 1 Reverse Gear

Brake System

Pneumatic

Steering Gear

Power Assistant

Wheel Base

3360(mm)

Front/Rear Axle Loading

2000/4800(Kg)

Approach/Departure Angle

24/16(°)

Tire

7.00-16

Max Driving Speed

100(km/h)

Upper Structure

LED Screen

Right LED Screen

3840mm(L)×1728mm(H)=6.63m2 P6 full-color Screen

Left LED Screen

3840mm(L)×1728mm(H)=6.63m2 P6 full-color Screen

Rear LED Screen

1280mm(L)×1440mm(H)=1.84m2 P6 full-color Screen

P6 full-color outdoor LED display, waterproof, shake-proof, high brightness, long life

Multi-media system

1.1 unit computer
2.Sound system including 4 units waterproof loudspeaker 1 unit power amplifiers

Generator Set

1.OUMA brand, Silent diesel generator

2.220V domestic power supply

Security system

Overheat protection

Remarks

1.Circulating ventilation and cooling systems

2.Aluminum patterned floor

3.Internal and external electrical distribution box

Optional Items

1.Mobile stage

2.Scrolling light box
