JAC 3 Ton 5 Ton 10 Ton Freezer Truck Refrigerator Truck Refrigerated Truck for Transport Ice Cream
Refrigerator truck is also called refrigerator truck, refrigerator wagon, refrigerated box truck,freezer wagon,temperature controlled truck,freezer truck. It is used to transport frozen or fresh goods, fresh Milk ,fresh vegetables and fruits, vaccine drugs etc. It is equipped with a refrigeration unit and polyurethane insulated van.
Description FEEDBACK
JAC 4X2 3 Ton 5 Ton 10 Ton  Freezer Truck Refrigerator Truck Refrigerated Truck for Ice Cream

Refrigerator truck is also called refrigerator truck, refrigerator wagon, refrigerated box truck,freezer wagon,temperature controlled truck,freezer truck. It is used to transport frozen or fresh goods, fresh Milk ,fresh vegetables and fruits, vaccine drugs etc. It is equipped with a refrigeration unit and polyurethane insulated van.


Chassis brand


CNHTC , Beiben trucks , Shacman trucks , FAW trucks , ISUZU ,Hongyan trucks,FOTON trucks , Dongfeng trucks , JAC trucks

 Technical date:
Chassis Model CLW5080XLC4 ,
Vehicle main dimension Overall dimension(LxWxH)mm 7150*2100*3130
  Chassis model HFC1081P71K1C6
  wheel base(mm) 3845/3815
  wheel track(front/rear)(mm) 1665/1525
  Overhang(front/rear)(mm) 1110/2195
  Approach/Departure angle 20/10
Weight in KGS GVW 8275
  Curb weight 4350
  Loading capacity 5000
  Front axles loading capacity /
  Rear axles loading capacity 5Tx1
Max driving speed(km/h) 90
Engine Brand Foton cummins
  Model ISF3.8S4154
  (CC)KW 3760/115
  Emission standard Europe IV
Transmission 5 gear box ,5 forward 1 reserve
Drive system LHD
Tire 7.50-16
Body Cargo body Dimension LxWxH 3100*1520*1560
    Material glass fiber reinforced plastics(color plate is for option)
    Thickness 8cm
    Other Stainless steel lock, stainless steel Contour corner protection, stainless steel door frame, dome light and Bumper block, two rear door
  Coolingsystem Brand ACCORDING TO CUSTOMER
    Model ACCORDING TO CUSTOMER
    power ACCORDING TO CUSTOMER
    Temperature ACCORDING TO CUSTOMER
  Option 1,Side door ,
2,refrigerator machine :thermoking, carrier ,and others you like
