Dongfeng RHD 10cbm 10000Liters Liquid Waste Sewage Vacuum Suction Truck

15000L Sewage Tank

Italian BP/BP/MORO Pump

Sewage Suction & Jetting

Auto Tipping & Washing

Description FEEDBACK

Dongfeng RHD 10cbm 10000Liters Liquid Waste Sewage Vacuum Suction Truck

15000L Sewage Tank

Italian BP/BP/MORO Pump

Sewage Suction & Jetting

Auto Tipping & Washing



Dongfeng RHD 10cbm 10000Liters Liquid Waste Sewage Vacuum Suction Truck

Description



--1. Chassis:

1) Drive type: 4x2, 4x4, 6x4, 8x4 etc.

2) Our factory has good business relationship with DONGFENG, FOTON, ISUZU, FAW, SINOTRUCK, SHACMAN, JAC, JMC, etc.

--2. Tanker body:From 2m3 to 25 m3 capacity.



--3. Accessory of sewage suction factions: Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.



verall dimensions

7800*2490*3900mm

GVW

15800kg

Chassis brand

China Dongfeng

Traction type

4*2

Chassis model

Dongfeng

Cab

one and a half row, all welded steel cab of tilt type,   mechanical cab tilting, rear mechanical cab suspension, adjustable driver‘s   seat, air conditioning system, electric windows, central lock.

Traction type

Right-hand drive

Drive type

4*2

Wheelbase

4500mm

Tire specification

10.00R20

Tire quantity

6+1 units

Engine

Engine model

CUMMINS 190HP

Emission level

Euro 2or3

Displacement/output

5900ml/140kw

Horse power

190hp

Gear box

Model

Dongfeng

Number of gears

6 forward gears& 1 reverse, synchronized

Suspension

Front

8/8- Leaf spring with shock absorber

Rear

9/9-Leaf spring

Fuel tanker

Type

Steel fuel tank, with lockable cap

Tanker Capacity

10,000cbm

Pump

Type

Italy BP Pump

Rating speed

1400(r/min)

Max vacuum - %

98%

Pipe

Suction and discharge pipe

Special function

Suction time ≤ 3mins,
  effective suction range ≥ 9,
  Max vacuum degree ≤ 15 Kpa,
  dump angle ≥ 45

Standard configuration

Equipped with Inspect window,discharge valve,cleaning    apparatus,5 meter long suction pipe,oil-water separators,    overflow valve,etc.
  Cylinder vacuum tank can be lifted hydraulically to
  40-45 degree. Rear door can be opened and closed hydraulically.

Optional configuration

Tanker material: stainless steel.
  Anti-rust coating inside tank

Remarks

The color and Logo can be customized.
