Sinotruck howo SS304 8000liter Portable Drinking Water Transport Truck

Main Specification

Driving Type

 4×2,left hand drive

Year

2022 new Model

Weights

Rated payload weight(kg)

3000-4000

Curb weight(kg)

3550

Dimensions

Wheelbase(mm)

3360

Overall Dimension(mm)

5995*2040*3000

 Max speed(km/h)

110

Engine

 Engine model

HOWO

Engine type

4 stroke water-cooled, supercharged and inter-cooled

No. of cylinders

straight-4 cylinders

Displacement(L)

2.77L

Horse Power

98hp

Emissions standard

Euro 4

 Drive Line

Transmission

MSB 5 speed,5 forwards,1 reverse gear,manual operation

Brake

Oil brake

Cab

cabin

HOWO

Axle

Front axle

2 tons

Rear axle

3 tons

Tire specification

Tire specification

700-15  standard tire,6 tires+1 spare tire

Special function of Water Tanker

Tank Material

SUS304-2B

Liner thickness

δ3.0 mm

Outsourcing thickness

δ1.0mm

Diameter of Water outlet

∮51mm

Insulation Materials

Polyurethane spray
Rubber insulation board

Insulation performance

No more than 2℃ in 24 hours

Tank head

Single layer butterfly head
Thickness 3mm

Pump

Model

60/30

Material

Stainless steel

Cleaning method

CIP cleaning device meets 360° cleaning requirements

Special function

1. The Water release switch and cleaning switch are made into a cluster structure, and each Water warehouse number is marked. Before the whole vehicle leaves the factory, the tank body is sprayed with the transportation medium and the announcement volume according to the announcement requirements. Elbow transition for cleaning unity.
2. The tank volume is 5000L,
3. The rear operating box is opened with a gas spring hatchback, and an opening handle is installed.
4. Each manhole cover and the rear toolbox are equipped with lead sealing devices to facilitate the management requirements when the Water truck loads and unloads fresh Water.
5. Configure a movable ladder for personnel to enter and exit the tank.
