HOWO 10 Ton Intelligent Asphalt Distribution Truck
Synchronous chip seal truck is one of the most successful road-resurfacing methods, designed to extend the life of a road‘s driving surface. The chip seal process involves applying a layer of asphalt emulsion and aggregate rock over the road. The process consists of liquid asphalt, immediately followed by rock chips.
Description FEEDBACK

HOWO 10 Ton Intelligent Asphalt Distribution Truck



Synchronous chip seal truck is one of the most successful road-resurfacing methods, designed to extend the life of a road‘s driving surface. The chip seal process involves applying a layer of asphalt emulsion and aggregate rock over the road. The process consists of liquid asphalt, immediately followed by rock chips.

Synchronous Chip Sealer can perform asphalt binder spraying and chip spreading processes synchronously, which allows full contact between binders and aggregates, thus resulting in maximum cohesive performance. It can also separately spray or spread asphalt or aggregate in special conditions.










Chassis specification
Item unit parameter
Truck model   CLW5160GLQZ5
Overall dimensions mm 8790x2480x2480
GVW kg Appro×16000
Mass in working order Appro×9200
Wheel base mm 4500
Exhaust/hp ml/hp 9726/140
Max speed km/h 190
Tire specification 12.00 Engine type WD615
Traction system 4×2 transmission 8speed with over drive and 1 reverse
Number of axles 2 Electric system 12V
Operation control  system Electrically hydraulic control Allowable passengers in cab 2
gear box description      Mechanical gear box 5 speeds+ one rear
Engine The truck, diesel engine, water cooled, direct injection,95 horse power





Special function
Specification
(intelligent models)
Asphalt tank Outline Dimension (mm) 4350/2300/1500
Asphalt tank Inner Dimension(mm) 4140/2090/1290
Asphalt tank Total Volume(L) 10000
Insulating layer thickness (mm) 50
Hydraulic pump CBQ550-L
Proportional valve EFBG-03-160-HF
Asphalt pump QGB950
Hydraulic motor for asphalt pump 05-110-BD31
Heating System Italian burner / Riello
Heat-transfer oil pump 25-25-160
Control System Intelligent control , Germany STW Model
Generator 6KW gasoline engine generator
Number of nozzle 36
Spray medium Hot asphalt/ Hot modified asphalt/ Cutback asphalt/ Emulsified asphalt
Spray width(m) 4.5
Spray amount(L/m2) 0.25-3.5L
