HOWO 15 Ton Intelligent Asphalt Distributor Truck
The asphalt distribution truck is equipped with an independent auxiliary engine power system to ensure zero start spraying.Asphalt sprayer adopts a three-section folding structure, which achieve double or multiple spraying by moving the spreader up and down, and expand the spread range and avoid obstacles meanwhile moving the spreader left and right.
Description
Get quotation
HOWO 15 Ton Intelligent Asphalt Distributor Truck
The asphalt distribution truck is equipped with an independent auxiliary engine power system to ensure zero start spraying.Asphalt sprayer adopts a three-section folding structure, which achieve double or multiple spraying by moving the spreader up and down, and expand the spread range and avoid obstacles meanwhile moving the spreader left and right.
Chassis specification |
Item | unit | parameter | ||
| Truck model | CL5250GLQZ5 | ||||
| Overall dimensions | mm | 10790x2480x2480 | |||
| GVW | kg | Appro×25000 | |||
| Mass in working order | Appro×13500 | ||||
| Wheel base | mm | 4500+1350 | |||
| Exhaust/hp | ml/hp | 9726/140 | |||
| Max speed | km/h | 190 | |||
| Tire specification | 12.00 | Engine type | WD615 | ||
| Traction system | 6×2 | transmission | 8speed with over drive and 1 reverse | ||
| Number of axles | 2 | Electric system | 12V | ||
| Operation control system | Electrically hydraulic control | Allowable passengers in cab | 2 | ||
| gear box description | Mechanical gear box 5 speeds+ one rear | ||||
| Engine | The truck, diesel engine, water cooled, direct injection,95 horse power | ||||
| Special function Specification (intelligent models) |
Asphalt tank Outline Dimension (mm) | 4350/2300/1500 | |||
| Asphalt tank Inner Dimension(mm) | 4140/2090/1290 | ||||
| Asphalt tank Total Volume(L) | 15000 | ||||
| Insulating layer thickness (mm) | 50 | ||||
| Hydraulic pump | CBQ550-L | ||||
| Proportional valve | EFBG-03-160-HF | ||||
| Asphalt pump | QGB950 | ||||
| Hydraulic motor for asphalt pump | 05-110-BD31 | ||||
| Heating System | Italian burner / Riello | ||||
| Heat-transfer oil pump | 25-25-160 | ||||
| Control System | Intelligent control , Germany STW Model | ||||
| Generator | 6KW gasoline engine generator | ||||
| Number of nozzle | 36 | ||||
| Spray medium | Hot asphalt/ Hot modified asphalt/ Cutback asphalt/ Emulsified asphalt | ||||
| Spray width(m) | 4.5 | ||||
| Spray amount(L/m2) | 0.25-3.5L | ||||
