HOWO 23cbm Synchronous Chip Sealer Truck for Sales
Synchronous chip seal truck is one of the most successful road-resurfacing methods, designed to extend the life of a road‘s driving surface. The chip seal process involves applying a layer of asphalt emulsion and aggregate rock over the road. The process consists of liquid asphalt, immediately followed by rock chips.
Description FEEDBACK

HOWO 8x4 23CBM Synchronous Chip Sealer Truck For Sales

Synchronous chip seal truck is one of the most successful road-resurfacing methods, designed to extend the life of a road‘s driving surface. The chip seal process involves applying a layer of asphalt emulsion and aggregate rock over the road. The process consists of liquid asphalt, immediately followed by rock chips.

Synchronous Chip Sealer can perform asphalt binder spraying and chip spreading processes synchronously, which allows full contact between binders and aggregates, thus resulting in maximum cohesive performance. It can also separately spray or spread asphalt or aggregate in special conditions.
Vehicle Description
Vehicle model Chip sealer Overall dimensions (mm) 12250x2500x3650
GVW (kg) Appro×31000 Fact loading capacity (L) 9000+14000
Mass in working order (kg) Appro×17370 Max. Speed (km/h) 90
Chassis Description
Chassis Model ZZ1317
Cab Standard cabin
Color Optional
Allowable person in cab 2/3
Wheel base (mm) 1300+4600+1350
Front/Rear track base (mm) 2022/1830/1830
Front/Rear overhang (mm) 1500/2545
Number of axles 4
Axle Front axle 7000/7000
Rear axle 13000/13000
Traction system 8x4
Operation control system Power steering
Braking system Full air
Electric system 24V
Transmission HW19710 10 speeds + 2 rear
Spring plate 9/12
Tire specification 12.00R20
Tire quantity 12+1
Engine Description
Engine manufacture SINOTRUK WEICHAI POWER CO., LTD
Engine model WD615.69
Emission standard Euro 2
Exhaust/output 9726/247
Horse power 336
Up-parts Description
Asphalt tank Total Volume(L) 9000
Chippings bucket Total Volume(L) 13000
Insulating layer thickness (mm) 80
Hydraulic pump 50-20-16
Proportional valve Taiwan EFBG-03-160-HF
Asphalt pump QGB680
Hydraulic motor for asphalt pump 05-110-BD31
Heating System Italian burner Riello (G20)
Heat-transfer oil pump 40-25-160
Control System SIEMENS  CLW-32-01
Generator 5.5KW gasoline engine generator
Number of nozzle 32
Spray medium Hot asphalt/ Hot modified asphalt/ Cutback asphalt/ Emulsified asphalt
Spray width(m) 4
Spray amount(L/m2) 0.3-3.5
Working Condition: 1,Altitude: 0-4500m
2,Temperature: -350C~+450C
3,Relative humidity: 80%
4,Wind force: ≤8 degree

Working Video
