Isuzu 4X2 10000liters 15000liters Stainless Steel Aluminum Alloy Liquid Tank Truck Oil Delivery Truck

Fuel tank truck: according to the different types of transport medium, configuration and different places called, there are many different titles, such as tank car, tank truck, oil truck, oil supply car, oil puller, flow refueling car, tax control refueling car, computer tanker, diesel transporter, gasoline transporter, coal tar carrier, Lubricating oil transporters, edible oil transport vehicles, crude oil transporters, heavy oil transporters, oil tanker and so on.

Description Get quotation

Isuzu 4X2 10000liters 15000liters Stainless Steel/Aluminum Alloy Liquid Tank Truck Oil Delivery Truck

All the tank trucks can be designed as chemical vehicles, all kinds of heating and insulation tanks; all the tank cars can be equipped with computer tankers; wide range of tonnage selection to meet the user‘s needs; the tank has multiple anti wave baffles. High pressure gas leakage test is used to make the tank body with high strength, stable center of gravity and safe and stable transportation of vehicles.

Description:

1. Tank material: we can provide carbon steel tanks, stainless steel tanks, manganese steel tanks, aluminum tanks, steel with plastic (or rubber) tanks and plastic tanks.

2. Good welding: tank body is adopted an advanced automatic vertical welding techniques and head arc butt welding technology, as well as the whole- steel forming a composite.

3. High safety: equip with active and passive emergency protection devices, to provide full closure remote manipulation of materials handing functions. Equip separators [Baffle] to prevent surging of liquid towards bulk head

4. Function: The tank body is suit for loading light fuel oil, heavy oil, sulfuric acid, hydrochloric acid, nitric acid, caustic soda hydrogen peroxide, alcohol, benzene, cooking oil and so on.

5. Oil punp: gear pump, self-absorption (centrifuge) pump, chemical pump, heavy, oil pump, stainless steel pump are optional.

6. Tank shape: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.

7. Refueling machine: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.

8. Optional: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.

General Technical Parameters
Overall Dimension	8350x2500x3300(mm)		Gross Vehicle Weight	18000(kg)
Curb Weight	6605(kg)		Loading Weight	12000(kg)
Chassis Specification
Chassis Parameters	Chassis Brand		ISUZU
	Cabin		Row and half, Left Hand Driving
	Engine	Power	190HP
		Emission standard	EURO IV
		Displacement	5.19L
		Fuel type	Diesel
	Gearbox		FAST 9 Forward & 1 Reverse Gear
	Front and Rear Axle load		6.3T/13T
	Wheel Base		4500(mm)
	Brake System		Pneumatic
	Steering Gear		Power Assistant
	Tire		900-20, 7 Pieces
	Maximum speed		90(km/h)
Tank Body
Shape	Monoblock Cylinder
Total Volume(m³)	15m3
Tanker Body Material	5mm carbon steel
Manhole Cover	∮500mm ,1 set with 1 breather valve
Bottom Valve	1 set
Discharging Valve	1 set ∮80mm discharging valve
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint
Accessories	One standard tool box
