Sinotruck HOWO RHD Diesel Road Garbage Vacuum Sweeper Street Suction Truck

A sweeper truck is a truck with brushes underneath for sweeping surfaces and gutters. They‘re often referred to as street sweepers or street cleaners, road sweeper, vacuum sweeper, etc, but they don‘t just clean streets. These versatile vehicles can be used in a number of ways. Any area that is paved can be cleaned with one of these trucks. They clean all manner of waste off of city streets, typically late at night or early in the morning, and they make street cleaning much more time-efficient than it used to be.

Description Get quotation

Sinotruck HOWO RHD Diesel Road Garbage Vacuum Sweeper Street Suction Truck

Different types of Street Sweeper

According to different Fuctions of the Sweeper Truck, we mainly can divide them into three types:

1. Vacuum Suction Truck, which has no sweepers but is with a long suction divice in the middle and two vice suction divices at side. This truck normally be used in the places where have heavy dust like ement factory, coal depot, seaports, etc.

2. Street Sweeper Truck, which is with a long suction divices in the middle and two sweepers at both sides. This type Truck can be used in streets where has little dust and garbages on the road could be easily cleaned.

3. Jetting Sweeper Truck, which has three fuctions: High pressure water jetting, Sweeping and Suction. This type truck not only has the sweeping and suction, but also can high pressure jetting garbages sticked on the ground. High Pressure Water Jetting Sweeper Truck makes road the cleanest.

Item		Parameter	Unit
Working Performance	Max sweep width	3.0	m
	Sweep speed	3-20	km/h
	Max sweep capacity	60000	m2/h
	Max inhalation of granularity	≥110	mm
	Angle of unloading	≥45	.
	Volume of water tank	2500	L
	Volume of garbage tank	5000	L
Driving Performance	Max speed	90	km/h
	Max gradeability	30	%
	Braking distance	≤10	m
	Min turning diameter	≤13.6	m
Fuel Performance	Fuel consumption(Driving)	≤12	L/100km
	Fuel consumption(Sweep working at 8km/h)	6.5	L/h
	Fuel consumption(Sweep working at 8km/h)	2.7	L/10000m2
Quality Parameters	Curb weight	4950	kg
	Rated capacity	2270	kg
	GVW	7350	kg
Dimension Parameter	Overall dimensions	695025003300	mm
	Wheelbase	3300	mm
	Track front	1504	mm
	Track rear	1530	mm
	Front suspension	1070	mm
	Rear suspension	1580	mm
	Approach angle	24	.
	Departure angle	13	.
	Minimum Ground Clearance	190	mm

Sinotruck HOWO RHD Diesel Road Garbage Vacuum Sweeper Street Suction Truck
