Shacman 5cbm to 16cbm Road Washing and Sweeper Truck Water Cleaning Vacuum Suction Truck
  • Shacman 5cbm to 16cbm Road Washing and Sweeper Truck Water Cleaning Vacuum Suction Truck
  • Shacman 5cbm to 16cbm Road Washing and Sweeper Truck Water Cleaning Vacuum Suction Truck
  • Shacman 5cbm to 16cbm Road Washing and Sweeper Truck Water Cleaning Vacuum Suction Truck
  • Shacman 5cbm to 16cbm Road Washing and Sweeper Truck Water Cleaning Vacuum Suction Truck
  • Shacman 5cbm to 16cbm Road Washing and Sweeper Truck Water Cleaning Vacuum Suction Truck
  • Shacman 5cbm to 16cbm Road Washing and Sweeper Truck Water Cleaning Vacuum Suction Truck
Shacman 5cbm to 16cbm Road Washing and Sweeper Truck Water Cleaning Vacuum Suction Truck
  • Best Choice for Road Sweeping with both Garbage Tank & Water Tank
    Garbage Tank: DN100 Suction Hose with 2 wheels Sunction Pan.
    Water Tank: with Water Filter & Level Gauge.
    Auxiliary Cummins Engine 140HP to Supply Power for the whole system.
    Wind Suntion System to suck up the garbage.
    Sweeping System: 4 Brush totally, 2 Brush at each side
Description FEEDBACK

Shacman 5cbm to 16cbm Road Washing and Sweeper Truck Water Cleaning Vacuum Suction Truck With Vacuum Sprinkler Cleaning System

Product Description
Best Choice for Road Sweeping with both Garbage Tank & Water Tank
Garbage Tank: DN100 Suction Hose with 2 wheels Sunction Pan.
Water Tank: with Water Filter & Level Gauge.
Auxiliary Cummins Engine 140HP to Supply Power for the whole system.
Wind Suntion System to suck up the garbage.
Sweeping System: 4 Brush totally, 2 Brush at each side

Specifications

Dongfeng Truck Chassis

Condition

New condition/Right hand drive/4x2

Chassis

Brand

Shacman

Curb weight(kg)

4460 kg

Wheelbase(mm)

3815 mm

Dimensions(mm)

7180  x 2260 x 2680 mm

Wheel track (front/rear) (mm)

1504/1425

Approach/Departure angle(°)

24/13

Axle Load(kg)

5280/4720

Max. driving speed(km/h)

90 km/h

Tire

Specifications

6pcs with one spare tire

Number

8.25-16

Clutch

Reinforced diaphragm clutch

Gear box

Manual type, 6 Forwards & 1 Reverse

Cabin

Left Hand Driving, 3 Passenger Allowed

Engine

Model

Diesel Engine, 4 Cylinders

Power(kw)/Horsepower(HP)

103 kw/140 HP

Emission standard

Euro IV

Brakes

Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake

Steering Gear

Power steering, hydraulic steering with power assistance

Sweeping System

Tank

Garbage tank

Tank material

Stainless steel 304

Tank volume(cbm)

4 CBM

Water tank

Tank material

Stainless steel 304

Tank volume(cbm)

2 CBM

Auxiliary engine

Model

ISUZU

Power(kw)

 102 kw/140HP

Brush

Quantity(pc)

2 pcs

Working area(m)

2.7-3.2 m

Cleaning

High pressure reel

18 meters

Remarks

1, With water sprayer-bar
2, Rear vacuum cleaner
3, Blower
4, Rear LED pilot lamp
5, Self unloading box body
6, The color will be designed on basis of your requirements.
