Hyundai 6 wheel Road Construction Spray Bitumen Distributor Truck
The BITUMEN SPRAYER is equipped with an independent auxiliary engine power system to ensure zero start spraying.Asphalt sprayer adopts a three-section folding structure, which achieve double or multiple spraying by moving the spreader up and down, and expand the spread range and avoid obstacles meanwhile moving the spreader left and right.
Description
Get quotation
Hyundai 6 wheel Road Construction Spray Bitumen Distributor Truck
The BITUMEN SPRAYER is equipped with an independent auxiliary engine power system to ensure zero start spraying.Asphalt sprayer adopts a three-section folding structure, which achieve double or multiple spraying by moving the spreader up and down, and expand the spread range and avoid obstacles meanwhile moving the spreader left and right.
Hyundai 6 wheel Road Construction Spray Bitumen Distributor Truck Technical date:
| Truck model | CLW5161GZZ8 | ||
| Cab | Hyundai cab with one sleeper, with power steering. Electronic flameout | ||
| Driving Type | 4*2 | ||
| Max Speed (km/h) | 90 | ||
| Overall dimension(mm) | 7760×2500×2880 (mm) | ||
| Mass in working order( kg) | 8495 | ||
| GVW( kg) | 16000 | ||
| Wheelbase(mm) | 4200 | ||
| Tire | 12.00R20 | ||
| Clutch | Single-plate dry diaphragm spring clutch | ||
| Steering | Hydraulic steering with power assistance | ||
| Gear box | 6-speed | ||
| Engine | Model | EURO II | |
| Horse power | 130HP | ||
| Braking system | Service Brake | Compressed air brake | |
| Park Brake | Spring energy | ||
| Eletric system | 24v | ||
| Upper-Body specification | |||
| Tank Volume (m3) | 8 | ||
| Asphalt pump discharge(L/min) | 300 | ||
| Distribution width measurement(mm) | 4500~6000 | ||
| Distribution height from ground level(mm) | 200~450 | ||
| Distribution quantitative(L/m2) | 0.2-3 | ||
| Burner | G10 | ||
| Asphalt pump | QGB270 | ||
| Asphalt pump hydraulic drive motor | 05-110-BD31 | ||
| Hydraulic pump | CBQ540-L | ||
| Control method | Manually controlled two by one | ||
| Heating Model | Thermal fuel Automatic heating | ||
| Conducting oil pump | 40-25-160 | ||
