Chassis

Size

6,330×2,200×2,720mm

GVW/Curb Weight

9,100kg/5,850kg

Wheelbase

3,360mm

Front/Rear Axle

3.3/5.8T

Tire

7.50R16 6+1 tires

Engine

Type

Diesel

Make/Model

FOTON CUMMINS/ISF3.8s3168/168hp/Euro 3

Transmission

Make/Model

WLY635

Gears

6F+1R

Operation

Manual

Cabin

Driving

FOTON AUMARK 4×2 Day Cab, Left-hand Drive

Type

Steel construction, Single Row, Flat

Passenger No.

3

Body System

Tanker Capacity

8CBM(6m³ garbage tank+2,000L water tank)

Material

Stainless steel 304

Thickness

Tank Body 6mm

Auxiliary Engine

Brand

JMC

Power

87HP

Air Blower

Type

High-pressure, centrifugal, sweeping truck specific

used blower

Working Speed

2600～2900r/min

Driving Mode

Drive by an ancillary engine, automatic clutch, V belt

powered

Sweeping Equipment

Type

Four-disc typed brooms equipped between the front and rear axle, symmetric on the right and left side of the truck driven by motors.

Sweep Width

2.6~3.2m.

Suction Equipment

Type

Full-floating suction nozzle, independent forward operation, hydraulic raise & lower 200mm diameter

suction port

Maximum Inhalation Particle Size

≥100mm
