Truck Specification

Chassis model

CL5250GYYN3G

Cab

BEIBEN NG80 cabin , with power steering.

Driving Type

6*4 Left hand driving

Max Speed (km/h)

99

Overall dimension（mm）

9465*2500*3370

GVW（kg）

25000

Mass in working order（kg）

11800

Tank Capacity (L)

25000

Wheelbase（mm）

4500+1350

F/R track base（mm）

2022/1847

F/R overhang（mm）

1410/2205

Approach/Departure Angel

12/12

Tire

11.00R20(10+1)

Clutch

Single-plate dry diaphragm spring clutch

Steering

Hydraulic steering with power assistance

Gear box

9-SPEED FAST GEAR BOX

Enging

Model

WP7.270E30

Fuel Type

Diesel fuel

Type

Water-cooled four-stroke,, direct injection, turbocharged

Exhaust（ml）

7140

Max output power/rotate speed (hp /rpm )

270/2300

Max torque/rotate speed(N.m/rpm)

1100/1100-1600

Braking  system

Service Brake

Compressed air brake

Park Brake

Spring energy

Auxiliary brake

engine exhaust brake

Eletric system

24v

Upper-Body  specification

Volume of tank

25m3

Tank shape

Quadrate

Material of tanker

5mm carbon steel

Color of the tanker

According your demands

Equipment

Oil pump

Transport medium

Diesel oil, gasoil or others

Fittings

PTO oil pump

An aluminum alloy European standard manhole

Fuel hose box fitted on both side of tank

An aluminum alloy sea valves

Two Fire extinguisher

One spare tyre

Ladder: For access to top of tank complete with cat walk on top of tank

Heavy-duty rear bumper
