Vacuum/Suction truck is used for removing and transporting sand, stones, bottles, cans, grease, sludge and other debris from sanitary sewer and/or drain lines or industrial applications, by strong suction action which is created by a vacuum pump. Although vacuum unit is basically equipped with a vacuum pump and a cylindrical debris tank, it’s possible to obtain versatility by adding hydraulic and pneumatic components such as hose boom, various types of suction hose reels, assembled on the tank rear door, or on the top of it. Equipment installed upon trucks, roll on - off, trailers, and semi-trailers, suitable for liquid suction or dry suction. Designed and built according to the city’s structure, sewer canals’ diameters, sludge’s character and mounted on 2 axle, 3 axle and 4 axle trucks with different tank and pump capacities.
General
|
Descriptions
|
Specifications and types
|
||||
Truck Brand
|
CLW BRAND
|
|||||
Chassis Brand
|
Dongfeng KR
|
|||||
Approx. Dimension
|
9000*2550*3550 (mm)
|
|||||
GVW./Curb Wt.
|
18000(Kg)/ 13400Kg
|
|||||
Cab
|
Cab Capacity
|
2 persons‘ seat
|
||||
Air Conditioner
|
Air Conditioner
|
|||||
Chassis
|
Drive Type
|
4*2,Right hand drive /Left hand drive
|
||||
Fuel Type
|
Diesel
|
|||||
Engine Make & Model
|
Cummins
|
|||||
Power
|
210hp/190Hp
|
|||||
Emission Standard
|
EURO III
|
|||||
Brake
|
Air Brake
|
|||||
Wheelbase/No.of axle
|
4500mm 4700mm /2
|
|||||
Tyre Specfication
|
1000R20
|
|||||
Tyre Number
|
6 tyres and 1 spare tyre
|
|||||
Max Speed
|
90 km/h
|
|||||
Paint
|
Automative metallic paint
|
|||||
|
Capacity
|
Vacuum Tanker:15CBM
|
||||
Water Tank :1CBM
|
||||||
Clean Part
|
Vertical suction
|
8-10 m
|
||||
Diameter of suction pipe |
Φ102mm
|
|||||
Maximum inhaled particles
|
Φ100mm
|
|||||
High-pressure pump
|
Brand
|
Pinfu Germany Technical
|
||||
Flow
|
215L/Min
|
|||||
|
|
Pressure
|
18MPA
|
|||
High pressure pipe
|
Inside Diameter
|
25mm
|
||||
Length
|
60M
|
|||||
Nozzle
|
8KG
|
1pcs
|
||||
80cm
|
1pcs
|
|||||
Jetting Part
|
Pump
|
Brand
|
Weichai
|
|||
Horse Power
|
375
|
|||||
Water circulation pump
|
SK-15/12
|
|||||
|
Vacuum Pipe
|
Inside Diameter
|
102mm
|
|||
Length
|
10M
|
|||||
Anti-overflow valve
|
||||||
Visual pollution tube
|
||||||
Tank lifting
|
||||||
Hydraulic opening of rear cover
|
||||||
A 600MM hydraulic quick opening at the rear
|
||||||
Quickly open the 150 ball valve on the left
|
||||||
3 pcs 100 ball valves on the right
|
