Dongfeng dfac Dollcar 5000liter 5bm Sewage Sewer Toilet Suck Excrement Suction Vehicle China Manufacture
  • Dongfeng dfac Dollcar 5000liter 5bm Sewage Sewer Toilet Suck Excrement Suction Vehicle China Manufacture
  • Dongfeng dfac Dollcar 5000liter 5bm Sewage Sewer Toilet Suck Excrement Suction Vehicle China Manufacture
  • Dongfeng dfac Dollcar 5000liter 5bm Sewage Sewer Toilet Suck Excrement Suction Vehicle China Manufacture
  • Dongfeng dfac Dollcar 5000liter 5bm Sewage Sewer Toilet Suck Excrement Suction Vehicle China Manufacture
  • Dongfeng dfac Dollcar 5000liter 5bm Sewage Sewer Toilet Suck Excrement Suction Vehicle China Manufacture
  • Dongfeng dfac Dollcar 5000liter 5bm Sewage Sewer Toilet Suck Excrement Suction Vehicle China Manufacture
Dongfeng dfac Dollcar 5000liter 5bm Sewage Sewer Toilet Suck Excrement Suction Vehicle China Manufacture
1.Drive type: 4x2, 4x4, 6x4, 8x4 etc.
2.Purpose: It used for city and factory sewer cleaning, it‘s one of our sanitation truck series. Our mission is assist urban sanitation project and make world cleaning!
3. Our factory has good business relationship with DONGFENG, FOTON, ISUZU, FAW, SINOTRUCK, SHACMAN, JAC, JMC, etc.
4. Tanker body:From 2m3 to 25 m3 capacity.
5. Accessory of sewage suction factions: Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.
Description FEEDBACK

Dongfeng dfac Dollcar 5000liter 5bm Sewage Sewer Toilet Suck Excrement Suction Vehicle China Manufacture


1.Drive type: 4x2, 4x4, 6x4, 8x4 etc.
2.Purpose: It used for city and factory sewer cleaning, it‘s one of our sanitation truck series. Our mission is assist urban sanitation project and make world cleaning!
3. Our factory has good business relationship with DONGFENG, FOTON, ISUZU, FAW, SINOTRUCK, SHACMAN, JAC, JMC, etc.
4. Tanker body:From 2m3 to 25 m3 capacity.
5. Accessory of sewage suction factions: Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.

Cabin

Driving type 4x2, single row

Vehicle Main Dimensions

Overall dimensions (L x W x H)mm

6200×2030×2220

Wheel base (mm)

3308

Wheel track (front/rear) (mm)

1960/1860

Approach/Departure angle(°)

28/32

Weight in KGS

Tare Weight

3590

Payload

3640

Front axles loading capacity

1800

Rear axles loading capacity

3500

Max. driving speed(km/h)

95

Engine

Brand

Chaochai

Horse Power(HP)

102HP

Emission standard

Euro V

Gearbox

5 forwards & 1 reverse

Brake

Air brake

Tire

7.00R16, 6 tires with one spare

Sewage Tank

Tank volume

4000Liters

Tank material

5mm carbon steel

Vacuum Pump

Chinese Vacuum Pump or Italy Vacuum Pump

Sewage suction pipe

6M

Main Performance

Suction time ≤ 5min,

effective suction range ≥ 8m

Other equipment

Oil-gas separator, water-gas separator, four-way valve, anti-flow valve, washing device, pressure gauge, ball valve

Painting

Customized painting color and logo as required.
